Crystal
Crystal 12MHz 18pf - 20pF, SMD3225-4 (4 pin)
| Reference | Package | Value | Quantity | Rating | Note |
|---|---|---|---|---|---|
| Y101 | SMD3225-4 | 12MHz 18pf - 20pF | 1 | <=+/-30ppm |
Any manufacturer crystal in 4 pin 3225 package. 18pF or 20pF, less than +/-30ppm frequency tolerance (we use +/-10ppm).
We prototyped with a smaller crystal, but the SMD3225 package is currently the cheapest and most available size.
Example:
